Paper detector, Detection Switches
SSS-19
※产品介绍以及详细介绍（PDF数据）只有英语版
- Superb reliability by our own sliding contacts mechanism.
- Light operating force for paper detection.
- Gold plated contact with high environment resistance is available.
- A wide variety of operation components.
- Suitable connector : Molex Japan SD-52484-0210
*Please contact us for the current production status.
Application
Typical Specifications
- Poles
- 1
- 1Positions
- 1
- Rating
- 20mA 5V DC
- Contact resistance
- 1Ω
- Operating life
- 100,000cycles
