Automotive Relay
RPP Series
- 12.2×21×8mm
- Surface mount type
*Please contact us for the current production status.
Typical Specifications
Typical Specifications
- Rating
- 25A 14V DC
- Max. switching power
- 480W
- Max. switching voltage
- 16V DC
- Max. switching voltage
- 960mW
- Withstanding voltage
- AC 500V
- Mechanical life
- 1.000.000 operations
- Electrical life
- 100,000 operations
