Push-type Detector Switches
SW-110-6
※产品介绍以及详细介绍（PDF数据）只有英语版
- Miniaturized for space saving design.
- Superior reliability at micro-current by employing a sliding contact.
- Available in wide variety of mounting methods , operating methods etc
*Please contact us for the current production status.
Application
Typical Specifications
- Poles
- 1
- Position
- 1
- Operating
force - 0.5N max
- Rating
- 100mA 12V DC
- Contact resistance
- 1Ω max
- Insulation resistance
- 100MΩ
- Withstanding voltage
- 100V AC for 1min
- Operating life with load
- 50,000cycles
