Push-type Detector Switches
SW1AG-530-102
- Miniaturized for space saving design.
- Superior reliability at micro-current by employing a sliding contact.
- This is a compact detector switch which is possible to detect 2 direction.
- Custom-made of the lever style is possible and please feel free to contact us beforehand.
*Please contact us for the current production status.
Application
Typical Specifications
- Poles
- 1
- Positions
- 1
- Operating force
- 0.3N max
- Rating
- 0.1～10mA 3～5V DC
- Contact resistance
- 1Ω
- Insulation resistance
- 100MΩ
- Withstanding voltage
- 100V AC for 1min
- Operating life
- 100,000cycles
